Product Overview. How To: Function Activation. Any of the below functions may be purchased at time of order or may be enabled in the field at a later date through a code activation process. The only exception is the AF travel measurement option, which also requires field hardware installation. A complete options package is also available, including all of the below features at a discounted price. The test stand is shipped in Demo Mode, during which time all available features are temporarily enabled for hours of operation.
Crosshead movement responds to manually pushing or pulling on the force gauge shaft or load cell. Increasing force produces greater speeds. Ideal for setups and quick positioning. If force vs. See below section for details. Increase the vertical clearance for tall samples.
Multiple extensions may be stacked for very long samples. Three heights are available - 6, 12 and 24 in [, , and mm].
Base contains rows of T-slots for fixture mounting. Ex: ESME. Mark defines accuracy as a percentage of full scale of the instrument.
This means that any displayed reading may be higher or lower by up to 0. For example, if the displayed value is The accuracies of the sensor and the indicator must be added together. Because of these fixed errors, lower measured values will be more inaccurate as a percentage of reading. To calculate the error as a percentage of reading, divide the fixed error by the measured value. For a 1. For a Because of the relationship between load and accuracy, we recommend selecting an instrument capacity as close as possible to the maximum measured load.
